Frequency Range: |
80Hz to 10kHz ±1dB on
axis |
|
60Hz - 13kHz +1 / -3dB on
axis |
Pickup Pattern: |
Cardioid |
Dynamic
Range: |
102dB |
Open Circuit Sensitivity: |
13mV / Pa |
Noise Floor: |
A weighted -
21dBA / Flat - 24dB |
Impedance: |
200 ohms |
Sound Input: |
123dB SPL
maximum |
Output Connector: |
XLR 3 Pin male. Pin (1)
ground, Pin (2) Hot, Pin (3) Neutral |
|
Works with: 200 ohm
balanced input. |
Power
Requirement: |
12 - 48V
phantom |
Material: |
Aluminum - Silver matte anodize
finish |
Cartridge Type: |
Pre-polarized condenser
with cardioid pattern. |
Size (L x Dia):
|
6½" x 5/8" body, ½"
capsule housing; |
Weight: |
2oz. |
Approvals: |
CE, RoHS and WEEE |
