| Frequency Range: |
80Hz to 10kHz ±1dB on
axis |
| |
60Hz - 13kHz +1 / -3dB on
axis |
| Pickup Pattern: |
Cardioid |
| Dynamic
Range: |
102dB |
| Open Circuit Sensitivity: |
13mV / Pa |
| Noise Floor: |
A weighted -
21dBA / Flat - 24dB |
| Impedance: |
200 ohms |
| Sound Input: |
123dB SPL
maximum |
| Output Connector: |
XLR 3 Pin male. Pin (1)
ground, Pin (2) Hot, Pin (3) Neutral |
| |
Works with: 200 ohm
balanced input. |
| Power
Requirement: |
12 - 48V
phantom |
| Material: |
Aluminum - Silver matte anodize
finish |
| Cartridge Type: |
Pre-polarized condenser
with cardioid pattern. |
| Size (L x Dia):
|
6½" x 5/8" body, ½"
capsule housing; |
| Weight: |
2oz. |
| Approvals: |
CE, RoHS and WEEE |
